| Product Description
Automatic Beverage Drinking Water Bottle OPP Hot Melt Glue Labeling Machine
Hot melt glue labeling machine is widely used for different material of container . The label cost is comparatively lower, it can meet the requirements of those users who have diverse kinds of the containers. It is the most economical models in cost to make mass production and intergrated operating. The equipment has massively used modularization design concept to make it easy and simple for users to change the bottles. Whether from the replacement of star wheel, guide plate or manual speed adjustment to automatic speed control, for example changing the label is only needed to change the program, the products concept of that the equipment is designed for users is embodied in everywhere.
| Product Details
|Technical Parameter
Automatic Hot glue labeling machine for drinking water | |||||
Model | HGL-09 | HGL-12 | HGL-15 | HGL-18 | HGL-18H |
Label heads | 9heads | 12heads | 15heads | 18heads | 18heads |
Capacity | 10000bph | 12000bph | 15000bph | 18000bph | 24000bph |
Labeling precision | ±1mm | ±1mm | ±1mm | ±1mm | ±1mm |
Max label height | 200mm(standard width,can be adjusted) | ||||
Max label diameter | 600mm | 600mm | 600mm | 600mm | 600mm |
Paper core hot melt | 152mm | 152mm | 152mm | 152mm | 152mm |
Weight | 2000kgs | 2300kgs | 2500kgs | 2800kgs | 3000kgs |
Main Function
1)The adjustment of label cutting blade is easy and simple.
2)Vacuum-grip cylinder is made of high hardness material,the additional old handler can reduce the frictions of labels and prevent static electriciy
3)The change-over of shape pars can be finished with in 10 minutes
4)The position of cutting blade can be quickly and accurately adjusted by manual control cabinet
5)Vacuum-grip cylinder and cutting unit adopt special material which are wearproof and heat protection
6)The self-adjustmen knob can reset the I-MARK position while change he cutting length of labels
Full Automatic OPP Hot Melt Glue Labeling Machine For Water Beer Juice PET Glass Bottle
Hot melt glue labeling machine is a labeling machine equipment that can be used for full circle labeling. The cut label pattern is complete and does not deform; always end mesh gluing, which saves 50% of hot melt compared with foreign full spray gluing equipment; deviation correction ±0.05 (mm); upper and lower label heat shrinkable hoop tightness; overall The labeling surface is smooth, there is no dislocation of overlap, no leakage, no glue opening.
More Products
bottle blowing machine
water tratement system
bottle filling machine
carbonated drink filling machine
5gallon big barrel filling machine
cans filling sealing machine
opp labeling machine
Linear shrink warpping with tray
| Auto Bottle Firm Shrink Wrapping Machine Packing&Shipping
| Company Profile
ZHANGJIAGANG MAERCK MACHINER CO.,LTD.
We are not only a machine manufacturer, we can also supply turnkey project according to customers’ request, including workshop design, machine layout design, water, gas, electric cable layout design, label and bottle design and so on. Our mission is to ensure customers’ plant properly working and help customers win their market.
Different capacity small bottle mineral water filling machine
| About Service
| FAQ
1.Q For a new starter, how can you help me start and run a water or beverage bottling plant?
